8 Channel Fiber Optic WDM Multiplexer SC UPC CWDM Mux / Demux Set ABS Module

  • 1
  • 2

Brand Name : New Light

Model Number : CWDM

Certification : ISO ,ROSH

Place of Origin : China

MOQ : 1

Price : 1~30

Payment Terms : T/T, Western Union, MoneyGram, paypal

Supply Ability : 1000000

Delivery Time : 7~15 working days

Packaging Details : export packing

mode type : single mode

Insertion Loss : ≤ 2.5 dB

Connector Type : SC/UPC

Nuber of Channels : 8 channel

wavelength : 1470-1610nm

Passband ripple : ≤0.30dB

return loss : ≥45dB

Derectivity : ≥50dB

fiber type : Corning SMF-28 ultra

Contact Now

8 channel SC UPC CWDM mux and demux set fiber optic coarse wavelength division multiplexer




Features
ABS Module
Low Insertion Loss
High Stability
Applications
CATV Links
WDM Systems
System Monitoring
Test and Measurement Equipment


ParametersSpecification
MUXDEMUX
Insettion Loss(dB)2.52.5
CWDM Central Wavelengths [λc] (nm)1470~1610
Passband (@-0.5dB bandwidth)(nm)±7.5
InsettionAdjacent Channel> 30
Non-Adjacent Channel> 40
Passband Ripple (dB)≤0.30
Polarization Dependent Loss (dB)< 0.30
Polarization Mode Dispersion (ps)< 0.10
Return Loss (dB)> 45
Directivity (dB)> 50
Maximum Optical Power (mw)500
Operating Temperature (℃)-5 ~ +75
Storage Temperature (℃)-40 ~ +85
Fiber TypeCorning SMF-28 Ultra
Connector TypeSC/UPC
Pigtail Length(m)1
Package Dimension (mm)100*80*10






1×N CWDM Mux/Demux Module

OADM
ITUChannels NumberApplication TypeCentral WavelengthFiber diameterFiber Length

Connector

1=100G

2=200G

4=4 Channels

8=8 Channels

16=16 Channels

M=Mux
D=DeMux

41=1410nm

43=1430nm

45=1450nm

47=1470nm

49=1490nm

51=1510nm
53=1530nm
55=1550nm
57=1570nm
59=1590nm

1=250um
2=900um
3=2.0mm
4=3.0mm
XX=Other

05=0.5m
10=1.0m
15=1.5m
20=2.0m
XX=Other

0=None
1=FC/APC
2=FC/PC
3=SC/APC
4=SC/PC
5=ST
6=LC
X=Other


Applications:

CWDM System
Add/Drop
PON Networks
CATV Links

8 Channel Fiber Optic WDM Multiplexer SC UPC CWDM Mux / Demux Set ABS Module

Compliance:

Telcordia GR-1209-CORE-2001
Telcordia GR-1221-CORE-1999
RoHS


Packaging : bags&carton box

  • Shipping: International Express: Fedex, DHL, UPS, TNT and EMS , by air or by sea ..If you have another

preferred carrier, please notify us in advance.
